分布式流处理与消息传递——Paxos Stream 算法详解

article/2025/8/6 2:02:15

在这里插入图片描述

Java 实现 Paxos Stream 算法详解

一、Paxos Stream 核心设计

二、流式提案数据结构

public class StreamProposal {private final long streamId;private final long sequenceNumber;private final byte[] payload;private final List<Long> dependencies;// 流式提案验证public boolean validateDependencies(SortedSet<Long> committed) {return committed.containsAll(dependencies);}
}

三、核心组件实现

1. 流式Proposer

public class StreamProposer {private final AtomicLong nextSeq = new AtomicLong(0);private final SortedSet<Long> uncommitted = new ConcurrentSkipListSet<>();private final BlockingQueue<Proposal> pipeline = new LinkedBlockingQueue<>(1000);public void submitProposal(byte[] data) {long seq = nextSeq.getAndIncrement();Proposal p = new Proposal(seq, data);uncommitted.add(seq);pipeline.offer(p);}@Scheduled(fixedRate = 100)public void processPipeline() {List<Proposal> batch = new ArrayList<>(100);pipeline.drainTo(batch, 100);sendBatchToAcceptors(batch);}
}

2. 批量Acceptor

public class BatchAcceptor {private final Map<Long, ProposalState> promises = new ConcurrentHashMap<>();private final NavigableMap<Long, Proposal> accepted = new ConcurrentSkipListMap<>();// 处理批量Prepare请求public BatchPromise handlePrepare(BatchPrepare prepare) {long maxBallot = prepare.getMaxBallot();BatchPromise promise = new BatchPromise(maxBallot);prepare.getProposals().parallelStream().forEach(p -> {if (p.ballot() > promises.getOrDefault(p.streamId(), 0L)) {promises.put(p.streamId(), p.ballot());promise.addAccepted(accepted.tailMap(p.streamId()));}});return promise;}// 处理批量Accept请求public void handleAccept(BatchAccept accept) {accept.getProposals().forEach(p -> {if (p.ballot() >= promises.getOrDefault(p.streamId(), 0L)) {accepted.put(p.streamId(), p);promises.put(p.streamId(), p.ballot());}});}
}

四、流式Learner实现

public class StreamLearner {private final NavigableMap<Long, Proposal> learned = new ConcurrentSkipListMap<>();private volatile long committedWatermark = 0L;// 持续学习提案public void onLearn(Proposal proposal) {learned.put(proposal.streamId(), proposal);// 检查连续提交while (learned.containsKey(committedWatermark + 1)) {committedWatermark++;deliverToApplication(learned.get(committedWatermark));}}// 生成快照public StreamSnapshot createSnapshot() {return new StreamSnapshot(committedWatermark, learned.headMap(committedWatermark));}
}

五、状态压缩优化

public class LogCompactor {private final ScheduledExecutorService scheduler = Executors.newSingleThreadScheduledExecutor();private final long compactionInterval = 60_000;public LogCompactor() {scheduler.scheduleAtFixedRate(this::compact, compactionInterval, compactionInterval, TimeUnit.MILLISECONDS);}private void compact() {long watermark = learner.getCommittedWatermark();Map<Long, Proposal> snapshot = learner.createSnapshot();persistSnapshot(watermark, snapshot);learner.purgeBefore(watermark);}private void persistSnapshot(long watermark, Map<Long, Proposal> snapshot) {// 使用Protobuf序列化SnapshotProto.Builder builder = SnapshotProto.newBuilder().setWatermark(watermark);snapshot.values().forEach(p -> builder.addProposals(ProposalProto.newBuilder().setStreamId(p.streamId()).setData(ByteString.copyFrom(p.data()))));writeToDisk(builder.build().toByteArray());}
}

六、网络层优化

1. 批量消息编码

public class BatchCodec {public byte[] encodeBatch(BatchPrepare batch) {ByteBuf buf = Unpooled.buffer(1024);buf.writeInt(batch.size());batch.getProposals().forEach(p -> {buf.writeLong(p.streamId());buf.writeLong(p.ballot());buf.writeInt(p.data().length);buf.writeBytes(p.data());});return buf.array();}public BatchPrepare decodeBatch(byte[] data) {ByteBuf buf = Unpooled.wrappedBuffer(data);int count = buf.readInt();List<Proposal> proposals = new ArrayList<>(count);for (int i = 0; i < count; i++) {long streamId = buf.readLong();long ballot = buf.readLong();int length = buf.readInt();byte[] payload = new byte[length];buf.readBytes(payload);proposals.add(new Proposal(streamId, ballot, payload));}return new BatchPrepare(proposals);}
}

2. 零拷贝传输

public class ZeroCopyTransport {private final FileChannel snapshotChannel;private final MappedByteBuffer mappedBuffer;public ZeroCopyTransport(String filePath) throws IOException {this.snapshotChannel = FileChannel.open(Paths.get(filePath), StandardOpenOption.READ, StandardOpenOption.WRITE);this.mappedBuffer = snapshotChannel.map(FileChannel.MapMode.READ_WRITE, 0, 1024 * 1024 * 1024);}public void sendSnapshot(StreamSnapshot snapshot) {snapshot.getProposals().forEach((id, p) -> {mappedBuffer.putLong(id);mappedBuffer.putInt(p.data().length);mappedBuffer.put(p.data());});mappedBuffer.force();}
}

七、故障恢复机制

1. 提案重放

public class ProposalReplayer {private final JournalLog journal;public void recoverProposals(long startSeq) {try (JournalReader reader = journal.openReader(startSeq)) {JournalEntry entry;while ((entry = reader.readNext()) != null) {proposer.replayProposal(entry.getProposal());}}}private class JournalReader implements AutoCloseable {private final RandomAccessFile raf;private long position;public JournalReader(String path) throws FileNotFoundException {this.raf = new RandomAccessFile(path, "r");}public JournalEntry readNext() throws IOException {if (position >= raf.length()) return null;raf.seek(position);long streamId = raf.readLong();int length = raf.readInt();byte[] data = new byte[length];raf.readFully(data);position += 12 + length;return new JournalEntry(streamId, data);}}
}

2. 快速视图变更

public class FastViewChange {private final BallotGenerator ballotGen = new HybridLogicalClock();public void handleViewChange() {long newBallot = ballotGen.next();// 收集最新接收的提案Map<Long, Proposal> latest = acceptor.getLatestProposals();// 选择新的主ProposerelectNewLeader(newBallot, latest);}static class HybridLogicalClock {private long physical = System.currentTimeMillis();private int logical = 0;public synchronized long next() {long now = System.currentTimeMillis();if (now > physical) {physical = now;logical = 0;} else {logical++;}return (physical << 16) | logical;}}
}

八、性能优化策略

1. 流水线处理

2. 内存池管理

public class ProposalPool {private static final int PAGE_SIZE = 1024 * 1024; // 1MBprivate final Deque<ByteBuffer> pool = new ConcurrentLinkedDeque<>();public ByteBuffer allocate() {ByteBuffer buf = pool.pollFirst();if (buf != null) return buf;return ByteBuffer.allocateDirect(PAGE_SIZE);}public void release(ByteBuffer buffer) {buffer.clear();pool.addFirst(buffer);}public void writeProposal(Proposal p, ByteBuffer buf) {buf.putLong(p.streamId());buf.putInt(p.data().length);buf.put(p.data());}
}

九、生产部署架构

十、监控与调优

1. 关键指标监控

指标名称	类型	告警阈值
提案吞吐量	Gauge	< 10k ops/s
平均提交延迟	Histogram	P99 > 200ms
未提交提案积压	Gauge	> 5000
视图变更次数	Counter	> 5次/分钟
内存池利用率	Gauge	> 90%

2. JVM调优参数

-server
-Xmx16g -Xms16g
-XX:+UseG1GC
-XX:MaxGCPauseMillis=200
-XX:InitiatingHeapOccupancyPercent=35
-XX:+UnlockExperimentalVMOptions
-XX:+UseNUMA
-XX:MaxDirectMemorySize=4g
